Sportsmatch

• Suits Tikka 15mm dovetails.
• Includes arrestor pin to suit Tikka T3 and T3x models.
• Also fits Tikka M55, M65, M590, M595, M695 and M695 Magnum.
• 2 pieces.

• HTO82 Mounts Two Piece 15mm Dovetail CZ527/Fox High 25mm Tub

• Quick release
• Extremely solid
• Can be clamped to scope tube

Quick release torch mount. The unit replaces the top cap on one of your Sportsmatch mounts so is extremely solid. Alternatively it can be clamped to the scope tube.

• A = 13mm
• B = 21mm
• Weight 98g

• A = 13mm
• B = 21mm
• Weight 98g

• 2 piece
• 30mm tube scopes
• For 17mm dovetail

30mm Diameter Body Tube Medium Height Suitable CZ550, CZ557, ZKK600/601/602 etc and appropriate Parker Hale bases.

SUITABLE 17MM DOVETAILS WILL MEASURE APPROXIMATELY 19MM AT THE WIDEST POINT (TOP)

Suit up to scope objective OUTER diameter 55mm - see guide below

• 2 piece
• 30mm tube scopes
• For 17mm dovetail

• Configuration: 2 Piece
• Ring Size (Diameter): 30mm
• Height: High
• Rail: Weaver / Picatinny
• Fixings (Rail & Top Cap): Cap= Allen head, Rail=Thumb Nut
• Retractable ‘Recoil Stop’ Pin: No
• Height: From bottom of clamp to bottom of scope tube – 15mm
• Weight: 108 grams

• Configuration: 2 Piece
• Ring Size (Diameter): 30mm
• Height: High
• Rail: Weaver / Picatinny
• Fixings (Rail & Top Cap): Cap= Allen head, Rail=Thumb Nut
• Retractable ‘Recoil Stop’ Pin: No
• Height: From bottom of clamp to bottom of scope tube – 15mm
• Weight: 108 grams

• 1" Diameter Body Tube High Range For 15mm and 17mm dovetails up to 56mm lens diameter (on most rifles)
• Includes removable arrestor pin.
• Distance from Bottom of mount to bottom of tube 22mm

• 2 piece
• 30mm tube
• For 13mm Dovetails e.g. most modern BSA air rifles, CZ452 American and early Weihrauch HW35

• 2 piece
• 30mm tube
• For 13mm Dovetails e.g. most modern BSA air rifles, CZ452 American and early Weihrauch HW35

• A = 21mm
• B = 21mm
• Weight = 111g

• 2 piece
• 30mm tube
• For 13mm dovetail

• 2 piece
• 30mm tube
• For 13mm dovetail

• A = 15mm
• B = 21mm
• Weight = 90g

• A = 22mm
• B = 21mm
Weight 124g
• Suits CZ 17mm dovetails such as CZ550, CZ557, ZKK600/601/602 etc BSA Monarch / Majestic etc centrefire rifles and Parker Hale bases.
• Includes removable arrestor pin

• A = 22mm
• B = 21mm
Weight 124g
• Suits CZ 17mm dovetails such as CZ550, CZ557, ZKK600/601/602 etc BSA Monarch / Majestic etc centrefire rifles and Parker Hale bases.
• Includes removable arrestor pin

• Weight 124g
• 1" Diameter Body Tube High Range Scope Mounts up to 56mm lens diameter on most rifles.
• Suits CZ 15mm dovetails such as CZ527 / Brno Model 1 / 2 & Fox.
• Includes removable arrestor pin.

• Weight 124g
• 1" Diameter Body Tube High Range Scope Mounts up to 56mm lens diameter on most rifles.
• Suits CZ 15mm dovetails such as CZ527 / Brno Model 1 / 2 & Fox.
• Includes removable arrestor pin.

• A = 22mm
• B = 21mm
• Weight 124g
• Suits Tikka 15mm dovetails.
• Includes arrestor pin to suit Tikka T3 & T3x rifles. Also fits Tikka M55 M65 M590 M595 M695 M695 Magnum.

• A = 22mm
• B = 21mm
• Weight 124g
• Suits Tikka 15mm dovetails.
• Includes arrestor pin to suit Tikka T3 & T3x rifles. Also fits Tikka M55 M65 M590 M595 M695 M695 Magnum.

• Fits all 1" Body Tube Diameter scope mounts manufactured by Sportsmatch, may not fit other makes.
• Eliminates canting of the rifle/scope for enhanced long range accuracy
• Weight - 14g

• Fits all 1" Body Tube Diameter scope mounts manufactured by Sportsmatch, may not fit other makes.
• Eliminates canting of the rifle/scope for enhanced long range accuracy
• Weight - 14g

• A: 13mm
• B: 21mm
• Weight: 108g

• A: 13mm
• B: 21mm
• Weight: 108g

• A = 16mm
• B = 21mm
• Weight = 94g

• A = 16mm
• B = 21mm
• Weight = 94g

• 2 piece
• 30mm tube scopes
• For 17mm dovetail

• 2 piece
• 30mm tube scopes
• For 17mm dovetail

• A = 13mm
• B = 21mm
• Weight = 98g

• A: 13mm
• B: 21mm
• Weight: 98g

• A: 13mm
• B: 21mm
• Weight: 98g

• 1 Piece Mount.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most MODERN airguns & .22 rimfire rifles).
• Tube Size: To fit 30mm diameter body tube scopes.
• Front Lens Size: Up to 44mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Double Clamp (four bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 15mm
• Dimension B: 120mm
• Dimension C: 78mm

• 1 Piece Mount.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most MODERN airguns & .22 rimfire rifles).
• Tube Size: To fit 30mm diameter body tube scopes.
• Front Lens Size: Up to 44mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Double Clamp (four bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 15mm
• Dimension B: 120mm
• Dimension C: 78mm

• Weight 111g
• 13mm Dovetails e.g. most modern BSA air rifles, CZ452 American and early Weihrauch HW35.
• PLEASE NOTE SUITABLE DOVETAILS WILL MEASURE APPROXIMATELY 13.5MM AT THE WIDEST POINT.
• Includes EASYFIT arrestor pin.

• Weight 111g
• 13mm Dovetails e.g. most modern BSA air rifles, CZ452 American and early Weihrauch HW35.
• PLEASE NOTE SUITABLE DOVETAILS WILL MEASURE APPROXIMATELY 13.5MM AT THE WIDEST POINT.
• Includes EASYFIT arrestor pin.

• Width:21.00 (cm)
• Height:3.00 (cm)
• Depth:9.00 (cm)

• For 25mm 1" Scopes
• 13mm Dovetail
• 2 piece
• For up to 56mm Lens

• For 1" diameter body tube scopes.
• 1 piece scope mount = very strong and proof against recoil slippage
• For 9-11mm and 3/8" dovetails = most modern air rifles and rimfires
• LOW height profile - 13mm base to ring bottom height. For scopes with maximum OUTER lens case diameter 50mm That's most 40mm non AO scopes but NOT 40mm AO (Adjustable Objective)
• Scope tube clearance - Distance from 1 piece base to ring is 2mm - so may not suit scopes with turret saddles that project below.
• Mounting length 110mm - Will not suit most compact scopes.
• Includes Easyfit removable arrestor pin.

• For 1" diameter body tube scopes.
• 1 piece scope mount = very strong and proof against recoil slippage
• For 9-11mm and 3/8" dovetails = most modern air rifles and rimfires
• LOW height profile - 13mm base to ring bottom height. For scopes with maximum OUTER lens case diameter 50mm That's most 40mm non AO scopes but NOT 40mm AO (Adjustable Objective)
• Scope tube clearance - Distance from 1 piece base to ring is 2mm - so may not suit scopes with turret saddles that project below.
• Mounting length 110mm - Will not suit most compact scopes.
• Includes Easyfit removable arrestor pin.

• 1 Piece Mount.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most modern airguns & .22 rimfire rifles).
• Tube Size: To fit 1" (25.4mm) diameter body tube scopes.
• Front Lens Size: Up to 56mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Single Clamp (two bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 24mm
• Dimension B: 120mm

• 1 Piece Mount.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most modern airguns & .22 rimfire rifles).
• Tube Size: To fit 1" (25.4mm) diameter body tube scopes.
• Front Lens Size: Up to 56mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Single Clamp (two bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 24mm
• Dimension B: 120mm

• Increases or reduces eye relief by 25mm.
• 2 Piece Mounts.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most MODERN airguns & .22 rimfire rifles).
• Tube Size: To fit 1" (25.4mm) diameter body tube scopes.
• Front Lens Size: Up to 45mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Reach Forward / Backward Design.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Double Clamp (four bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 19mm
• Dimension B: 21 \ 46mm

• Increases or reduces eye relief by 25mm.
• 2 Piece Mounts.
• Base Fitting: 9.5 - 11.5mm (3\8") Dovetails - Most popular size (suits most MODERN airguns & .22 rimfire rifles).
• Tube Size: To fit 1" (25.4mm) diameter body tube scopes.
• Front Lens Size: Up to 45mm - This figure describes the maximum size of the objective (front) lens the mount is designed for when the dovetails are flush with the barrel. Please bear in mind scopes with front PX adjustment will often need higher mounts.
• Reach Forward / Backward Design.
• Bolt Type: Allen Key bolts - Allen Key(s) Supplied.
• Clamp Design: Double Clamp (four bolts on each cap).
• With removeable recoil stop pin.
• Dimension A: 19mm
• Dimension B: 21 \ 46mm

• Configuration: 2 Piece
• Ring Size (Diameter): 1″
• Height: Medium
• Rail: Dovetail (3/8″) 9.5-11.5mm
• Fixings (Rail & Top Cap): Hex Screw
• Retractable ‘Recoil Stop’ Pin: Yes
• Height: From bottom of clamp to bottom of scope tube – 19mm
• Weight: 70grams

• Configuration: 2 Piece
• Ring Size (Diameter): 1″
• Height: Medium
• Rail: Dovetail (3/8″) 9.5-11.5mm
• Fixings (Rail & Top Cap): Hex Screw
• Retractable ‘Recoil Stop’ Pin: Yes
• Height: From bottom of clamp to bottom of scope tube – 19mm
• Weight: 70grams

• 2 piece rings for 9.5-11.5mm grooves
• For 1" scopes up to 32mm lens dia. on most rifles
• A = 13mm B = 16mm
• Weight 56g
• Includes removable arrestor pin

• 2 piece rings for 9.5-11.5mm grooves
• For 1" scopes up to 32mm lens dia. on most rifles
• A = 13mm B = 16mm
• Weight 56g
• Includes removable arrestor pin

• HTO83 Mounts Two Piece 17mm Dovetail CZ550/P-Hale High 25mm

• Sportsmatch HTO89 - High height for scopes up to 56mm lens.

• Medium height
• For scopes up to 50mm lens
• 2 pieces

• Suitable for all Weaver / Picatinny rails
• Includes square section hardened steel arrestor bolt
• Up to 56mm lens diameter
